Suit Machine Types: Skid steer loaders, front end loaders and telehandlers.
Optional Extras:
Ideal Use:
Sweeps and collects all kinds of debris in
factory car parks, road construction, stock yards & more.
Cleana Bucket Broom Specifications |
BR-000410 24 X 1600 |
BR-000445 24 X 1600 |
BR-000414 24 X 1700 |
BR-000454 24 X 1700 |
BR-000416 24 X 1800 |
BR-000446 24 X 1800 |
---|---|---|---|---|---|---|
STD | HIGH FLOW | STD | HIGH FLOW | STD | HIGH FLOW | |
A Height (overall) | 699mm | 699mm | 699mm | 699mm | 699mm | 699mm |
B Depth (overall) | 1262mm | 1262mm | 1262mm | 1262mm | 1262mm | 1262mm |
C Width (overall) | 1870mm | 2010mm | 1971mm | 2110mm | 2071mm | 2210mm |
D Motor Width | 174mm | 309mm | 174mm | 309mm | 174mm | 309mm |
Max Flow (LPM) | 30-75 | 75-230 | 30-75 | 75-230 | 30-75 | 75-230 |
Max Pressure (BAR) | 205 | 240 | 205 | 240 | 205 | 240 |
Weight | 397kgs | 422kgs | 413kgs | 438kgs | 429kgs | 454kgs |
Cleana Bucket Broom Specifications |
BR-000418 24 X 2000 |
BR-000465 24 X 2000 |
BR-000420 24 X 2500 |
BR-000475 24 X 2500 |
BR-000010 24 X 3000 |
---|---|---|---|---|---|
STD | HIGH FLOW | STD | HIGH FLOW | HIGH FLOW | |
A Height (overall) | 699mm | 699mm | 699mm | 699mm | 699mm |
B Depth (overall) | 1262mm | 1262mm | 1262mm | 1262mm | 1262mm |
C Width (overall) | 2270mm | 2410mm | 2710mm | 2910mm | 3407mm |
D Motor Width | 174mm | 309mm | 174mm | 309mm | 309mm |
Max Flow (LPM) | 30-75 | 75-230 | 30-75 | 75-230 | 75-230 |
Max Pressure (BAR) | 205 | 240 | 205 | 240 | 240 |
Weight | 461kgs | 486kgs | 541kgs | 566kgs | 621kgs |
An open face broom is a bucket broom with an open front allowing you to sweep right up against walls and gutters. Quality Australian made featuring hi performance hydraulic components, heavy duty wheels, replaceable wear edge on bucket and removable side shift frame. Range of sizes available; 1600mm, 1800mm and 2000mm
Suit Machine Types: Skid Steer Loaders, Front End Loaders and Tele-Handlers.
(extra charge may be incurred for machines other than skid steer loader)
Ideal Use:
• Sweeps and collects all kinds of debris in factory car parks, road construction, stock yards, shipping containers and more.
• Sweeps right up against structures, walls and gutters
Machine Suitability:
• Skid Steer Loaders, Front End Loaders and Tele-Handlers.(extra charge may be incurred for machines other than skid steer loader and non standard frames)
Cleana Open Face Bucket |
BR-001153 24 X 1600 |
BR-001133 24 X 1600 |
BR-001160 24 X 1800 |
BR-001139 24 X 1800 |
BR-001169 24 X 2000 |
BR-001163 24 X 2000 |
---|---|---|---|---|---|---|
STD |
HIGH FLOW |
STD |
HIGH FLOW |
STD |
HIGH FLOW |
|
Height (overall) | 740mm |
740mm |
740mm |
740mm |
740mm |
740mm |
Length (overall) | 1855mm |
2000mm |
2055mm |
2200mm |
2255mm |
2400mm |
Depth (overall) | 1120mm |
1120mm |
1120mm |
1120mm |
1120mm |
1120mm |
Motor Width | 174mm |
309mm |
174mm |
309mm |
174mm |
309mm |
Max Flow (LPM) | 75 |
230 |
75 |
230 |
75 |
230 |
Max Pressure (BAR) | 205 |
240 |
205 |
240 |
205 |
240 |
Weight | 397kgs |
422kgs |
429kgs |
454kgs |
461kgs |
486kgs |
Brush Diameter | 24" |
24" |
24" |
24" |
24" |
24" |
